XWD-C型旋轉磁場搖枕、側架磁粉探傷機

適應范圍：

適應于鐵路貨車走行部搖枕、側架的磁粉探傷檢測

特點及技術指標

1.   采用自主知識產權的旋轉磁場磁化技術對檢測工件非接觸磁化，探傷表面磁場強度分布均勻，檢測可靠，適應能力強

2.   檢測工件一次通過隧道式磁化裝置即可完成探傷，檢測效率高

3.   獨特的工件夾持及定位鎖緊結構可同時兼容多種搖枕、側架的探傷作業

4.   磁化電流由可控硅調壓模塊控制，電流大小可根據檢測的需要隨時調整

5.   零件可自動360°自由回轉，并實現動態換向，便于觀察磁痕

6.   探傷過程采用PLC控制，操作應簡便可靠。一次性完成工件的轉動、磁化裝置的移動，噴淋及磁化過程，避免了影響探傷的人為因素

7.   整機為床式一體化設計，無須特殊基礎，安裝維修簡便

8.   輸入功率：60kW

9.   磁化方式：旋轉磁場

10. 磁化峰值電流：0-2500A連續可調

11. 檢測靈敏度：清晰顯示A1型標準試片 15/50的人工缺陷

12. 檢測部位表面磁場強度：≥2400A/m

13. 退磁效果：不大于0.3mT

14. 磁化線圈斷面尺寸：870×870mm

15. 磁懸液箱容量：80L

16. 可檢搖枕、側架最大長度：2800mm

17. 可檢搖枕、側架最大重量：800kg

18. 主機外形尺寸：6.0×1.7×2.2m

19. 主機總重量：4800kg

XWD-C Magnetic Particle Flaw Detector for swing bolster and side frame

Applicable scope

For the magnetic particle testing of swing bolster, bogie side frame of rolling stock

Features and Technical parameters

1.        Adopt to the independent intellectual property rights of rotating magnetic field non-contact magnetization, magnetic field distribution more uniform, use and reliable

2.        By inspecting through a tunnel magnetizing device can complete detection, high detection efficiency

3.        Unique work both clamping  swing bolsters and side frames can be also compatible with a variety of flaw detection

4.        Magnetizing current controlled by SCR module of voltage regulation, current can be adjusted at any time according to the need of the inspection

5.        Adopted the variable frequency drive to control work piece rotation, speed can be set freely and realize dynamic commutation, easy to observe the magnetic mark

6.        Inspection process adopts PLC programmable controller control, easy operation and reliable

7.        Bed struct integration design, without special foundation, easy installation and maintenance

8.        Magnetization mode: rotating magnetic field

9.        Input power: 60kW

10.    The peak value current of rotating magnetization:0-2500A continuously adjustable

11.    Detecting sensitivity: Clearly displays the artificial defect of A1 standard test piece 15/50

12.    Magnetic intensity of testing parts surface: ≥2400A/m

13.    Residual Field: ≤0.3mT

14.    Magnetization coil inner cavity section size: 850×850mm

15.    Magnetic suspension tank capacity:80L

16.    maximum length can be detected:2800mm

17.    maximum weight can be detected:800mm

18.    Mainframe exterior size: 6.0m×1.7m×2.2m

Mainframe weight: 4800kg
